EA15A-2 AVR Automatic Voltage Regulator brushless generator excitation Stabilizer alternator Controller Module

EA15A-2 AVR Automatic Voltage Regulator brushless generator excitation Stabilizer alternator Controller Module

Test before shippment, 1 year warranty, pay safe with PayPal.

Regular price $68.00
Regular price Sale price $68.00
Sale Sold out
Shipping calculated at checkout.

high quality EA15A-2 AVR brushless generator excitation Automatic Voltage Regulator alternator Controller ModuleStabilizer

Vltage Regulation < ±1%

Soft Start Voltage Ramping

Sensing Voltage Loss Protection

120 or 240 VAC Sensing, Jumper Selectable

Under Frequency Roll Off Protection

With Under Frequency LED Indicator

Sensing Input:

Voltage:220/380/440VAC , 1 phase 2 wire

Frequency:50-60Hz nominal

Voltage input:100-300VAC

Field output:

Voltage:max90VDC at 240VAC input

Current:continuous 5A,intermittent 20A for 10 se

Resistance:15 ? minimum

Regulation:+/-0.5% RMS with 4% engine governing

Voltage build up: residual voltage at avr terminal >5VAC

External Voltage Adustament:+/15% with 5k ohm 1 watt trimmer
